Kanal vazduha
51_2207 · BMW E38 740i M62 · Oprema karoserije (unutra i spolja)
| Poz. | Broj dela | Opis | Kol. |
|---|---|---|---|
| 01 | 51 71 8 177 609 | Prednji kanal vazduha · Front air duct | 1 |
| 02 | 51 71 8 168 197 | Zaptivka nosača leve prednje ploče · Left front panel support sealing | 1 |
| 02 | 51 71 8 168 198 | Right front panel support sealing | 1 |
| 03 | 51 71 8 163 833 | Poklopac zaštite motornog prostora · Cover, engine compartment screening | 1 |
| 04 | 51 71 8 150 223 | Prednji desni naslon za ruku · Engine compartment screening, front | 1 |
| 05 | 51 71 8 125 967 | Kanal vazduha prednje leve kočnice · Front left brake air duct | 1 |
| 05 | 51 71 8 125 968 | Prednji desni kanal za vazduh kočnice · Front right brake air duct | 1 |
| 06 | 51 71 8 163 835 | Bočna leva zaštita motornog prostora · Lateral left engine compartm.screening | 1 |
| 06 | 51 71 8 163 836 | Bočna zaštita motornog prostora, desna · Lateral right engine compartm.screening | 1 |
| 07 | 51 71 8 174 857 | Front airduct link | 1 |
| 08 | 51 71 8 168 107 | Premaz podvozja · Underfloor coating | 1 |
| 08 | 51 71 8 158 548 | Premaz podvozja · Underfloor coating do 09/1998 | 1 |
| 09 | 51 71 8 202 965 | Nosač donje obloge, levi · Bracket underfloor panelling, left do 09/1994 | 1 |
| 09 | 51 71 8 202 966 | Nosač donje obloge, desno · Bracket underfloor panelling, right do 09/1994 | 1 |
| 09 | 51 71 8 202 967 | Nosač donje obloge, levi · Bracket underfloor panelling, left do 03/1996 | 1 |
| 10 | 51 71 8 166 632 | Poklopac zaštite podvozja · Underfloor coating cover | 1 |
| 10 | 51 71 8 171 972 | Poklopac zaštite podvozja · Underfloor coating cover do 03/1996 | 1 |
| 11 | 51 71 8 163 841 | Spoljna leva obloga · Cover panel outer left | 1 |
| 11 | 51 71 8 163 842 | Spoljna obloga, desna · Cover panel outer right | 1 |
| 11 | 51 71 8 172 661 | Spoljna leva obloga · Cover panel outer left do 09/1998 | 1 |
| 11 | 51 71 8 172 662 | Spoljna obloga, desna · Cover panel outer right do 09/1998 | 1 |
| 11 | 51 71 8 242 710 | Spoljna obloga, desna · Cover panel outer right do 09/1998 | 1 |
| 11 | 51 71 8 242 719 | Spoljna leva obloga · Cover panel outer left do 09/1998 | 1 |
| 12 | 51 71 8 201 163 | Gornja leva obloga motornog prostora · Upper left engine compartment cover | 1 |
| 12 | 51 71 8 201 164 | Gornji desni poklopac motornog prostora · Upper right engine compartment cover | 1 |
| 12 | 51 71 8 231 455 | Gornja leva obloga motornog prostora · Upper left engine compartment cover do 12/1996 | 1 |
| 12 | 51 71 8 231 456 | Gornji desni poklopac motornog prostora · Upper right engine compartment cover do 12/1996 | 1 |
| 13 | 51 71 8 209 028 | Upper engine compartment cover lid | 2 |
| 13 | 51 71 8 231 737 | Grommet f upper cover do 12/1996 | 1 |
| 14 | 51 71 8 150 450 | Donja desna obloga prostora motora · Lower right engine compartment cover | 1 |
| 14 | 51 71 8 150 449 | Donja leva obloga motornog prostora · Lower left engine compartment cover | 1 |
| 14 | 51 71 8 195 374 | Donja desna obloga prostora motora · Lower right engine compartment cover do 09/1998 | 1 |
| 15 | 51 71 1 916 017 | Samourezni zavrtanj · Screw, self tapping | 3 |
| 16 | 07 12 9 904 150 | Navrtka za karoseriju · Body nut | 3 |
| 17 | 51 71 8 190 602 | Šelna · Clamp | 2 |
| 18 | 07 14 7 137 416 | Samourezni zavrtanj sa cilindričnom glavom · Fillister head self-tapping screw | 3 |
| 19 | 07 12 9 904 217 | Navrtka za karoseriju · Body nut | po potrebi |
| 20 | 07 11 9 901 299 | Zavrtanj sa šestougaonom glavom · Hex head screw | po potrebi |
| 21 | 63 17 1 367 868 | Proširujuća navrtka · Expanding nut | po potrebi |
| 22 | 51 71 8 176 504 | Podloška · Washer | 6 |
| 23 | 51 71 8 176 503 | Šelna · Clamp | 6 |
| 24 | 51 71 8 218 323 | Čep za ispuštanje ulja · Screw plug | po potrebi |
| 24 | 51 71 8 218 852 | Čep za ispuštanje ulja · Screw plug | 2 |
| 25 | 51 71 8 195 383 | Osigurač · Circlip | 4 |
| 26 | 17 11 1 712 963 | Proširujuća zakivna nitna · Expanding rivet | po potrebi |
| 26 | 51 47 1 911 992 | Proširujuća zakivna nitna · Expanding rivet | 2 |
| 27 | 07 11 9 904 517 | Šestougaoni zavrtanj sa podloškom · Hex Bolt with washer | 1 |
| 28 | 51 71 8 207 201 | Nosač zaštite motornog prostora · Engine compartment protection bracket | 1 |
| 30 | 51 71 7 004 421 | Zaptivka · Sealing | 1 |
| 31 | 51 71 8 264 395 | Bočna leva zaštita motornog prostora · Lateral left engine compartm.screening | 1 |
| 31 | 51 71 8 235 260 | Bočna zaštita motornog prostora, desna · Lateral right engine compartm.screening do 09/1998 | 1 |
Napomene iz kataloga
- without absorber
- For vehicles with Wading depth
- Za vozila sa aktivnim tempomatom
Brojeve delova proveri po VIN-u pre kupovine: u katalogu isti deo ima više izvedbi, zavisno od motora i godišta proizvodnje.
